This 700TVL CMOS Camera can be used as both PAL and NTSC. The toggle switch is provided on the camera by which you can enjoy the operation of PAL or NTSC mode. This camera is very compact and easy to use. This camera is tailored for FPV, dedicated to FPV HD aerial camera. It creates the delicate clear image, micro ultralight design, high definition color
Features:
- Lens:2.1mm
- Min illumination:0.001Lux/1.2F
- Power: DC 5V-30V
- Electronic Shutter Speed: PAL
- Horizontal Resolution:1500TVL
- Day/Night:Auto/Color/B*W
- Signal System: PAL/NTSC
- DNR:3DNR
- Illumination, the effect is a good, quality-assured, ultra-small size, very suitable for FPV
- Color fidelity, low illumination, micropower consumption
Package Includes:
1 x 700TVL Mini FPV Camera 2.1mm Lens PAL / NTSC
| Specifiacation | |
|---|---|
| Lens | 2.1mm |
| Image Sensor | 1/3'' CMOS |
| Horizontal Resolution | 700TVL |
| Min illumination | 0.001Lux/1.2F |
| Signal System | PAL/NTSC (OSD Internal adjustable) |
| Auto Gain Control(AGC) | LOW/MIDDLE/HIGH |
| S/N Ratio | more than 60Db(AGC OFF) |
| Backlight Compensation(BLC) | YES |
| Electronic Shutter Speed | PAL |
| DNR | 3DNR |
| WDR | D-WDR |
| Power | DC 5V-12V |
| Dimensions | 19mm*19mm*19mm |
| Net Weight | 6.0g |
| Shipment Weight | 0.02 kg |
| Shipment Dimensions | 5 × 5 × 4 cm |
